What is load cell system?

What is pneumatic load?

  • Pneumatic Load Cell. If a force is applied to one side of a diaphragm and an air pressure is applied to the other side, some particular value of pressure will be necessary to exactly balance the force. This pressure is proportional to the applied force.

What is load cell capacity?

  • Capacity: This is the maximum capacity the load cell is designed for. The load cell will output a signal that is proportional to any force applied up to and beyond this value. In general, it's not recommended to exceed the capacity by more than 10% or damage may result.

image-What is load cell system?
image-What is load cell system?
